The gypsum board production line is a special equipment for the production of new building materials gypsum board. Its main working process is: automatically and accurately measure the plaster, water and various additives, and enter the mixer through a continuous and automatic transmission system to mix and stir. Disperse it on the protective paper of the gypsum board which is continuously moving forward. During the advancement process, after vibration, the slurry is gradually dispersed and uniformly distributed. When it reaches the forming station, it is compounded with the back of the gypsum board and passed through extrusion. In the molding machine, the slurry is completely enclosed by the upper and lower cardboards and extruded into a regular flat plate. The flat plate continues to move forward at a strictly controlled and stable speed on the continuous production line, and gradually forms a wet gypsum board with a certain strength and regular shape. In the cutting system under precise automatic control, cut into veneers according to the set size. The veneers are arranged in an orderly manner through the program control system, turned over, and enter the dryer. Under the strictly controlled drying temperature, the adsorbed water in the boards is evaporated. After the board comes out of the dryer, the temperature is gradually reduced as the production line advances. After turning over again, each two boards are stacked on the front side, and the two ends of the boards are cut into standard size by the end saw, and then transferred to the automatic stacker, stacked into a neat and regular finished product into the warehouse.

The production line is mainly composed of six parts: raw material processing system, mixed batching system, forming and conveying equipment, dryer and drying system, dry plate conveying and stacking system, and electric control system.

Gypsum board production line equipment video display

1. Raw material processing system

It consists of jaw crusher, bucket elevator, electromagnetic vibrating feeder, hammer crusher, screw conveyor, column mill, classifier, arch breaking feeder, vibrating feed hopper, electric dust removal and electric control, system It consists of boiling furnace, system Roots blower, system blower and electric control equipment.

2. Mixed batching system

It is composed of bucket elevator, screw conveyor, manual butterfly valve, vibrating feeder, belt scale, electric hoist, hydraulic pulper, single screw pump, pulp mixer, water tank, and foaming station

3. Forming conveying equipment

It consists of uncoiling device, pulling device, adjusting device, tensioning device, slotting machine, vibrating table, forming machine, forming station, No. 1 coagulation belt conveyor, No. 2 coagulation belt conveyor, No. 3 coagulation belt conveyor, mixer, conveyor roller It is composed of conveyor, cutting machine, close roller conveyor and distributor.


Forming machine extrusion forming table


Ground conveyor roller


Mixing mixer


Close to roller table and distributor


Solidification belt conveyor


Cutting machine

4. Dryer and drying system

Dryer/dryer side air duct

Out of the dryer

Dryer gate/dryer outlet and coagulation belt conveyor

Dryer factory trial assembly

5. Dry board conveying and stacking system

It consists of a plate ejector, a dry plate belt conveyor, a No. 2 horizontal conveyor, a waste plate roller, a No. 2 horizontal rear transition belt conveyor, a sheeting machine, a 3# horizontal conveyor, a sawing machine (including an edge banding machine), and a stack Plate conveyor, plate storage machine, small plate stacking conveyor, positioning and palletizing chain plate hydraulic table, chain plate machine




No. 2 Lateral Transition Belt Conveyor


Belt conveyor after publication


Filming machine


Horizontal machine


Saw edge machine


Hydraulic lifting table

6. Electronic control system

Computer monitoring system, low-voltage power distribution panel, transformer, cable, bridge frame and auxiliary materials
